PCE-N24H Current Indicator

Product form

SKU: PCE-N24H-1100A0E0

Delivery 48–72h

€109,09 Incl. VAT

    • Secure & regulated transaction

      stripe

    Ficha técnica

    Especificaciones del producto
    Tipo de productoCurrent indicator
    Peso 0,2 kg
    Componentes incluidos 1 unidad

    Documentación técnica y cumplimiento

    Compra para empresa (B2B)

    • Acceso a catálogo profesional con precios visibles para empresa, taller o profesional.
    • Compra directa sin necesidad de solicitar presupuesto.
    • Referencias estándar para reposición continua sin cambios.
    • Para pedidos de mayor volumen o consumo recurrente, aplicamos condiciones adicionales.

    Acceder a condiciones para empresa

    Envío y devoluciones

    • Entrega 48–72 h laborables en España (Península/Baleares) y Portugal.
    • Coste y plazo exactos se calculan en el checkout según destino y peso.
    • Devoluciones en 30 días (consulta condiciones en la política de devoluciones).
    • Incidencias reemplazo o reembolso en caso de producto dañado o defectuoso.
    • Factura disponible para empresas, autónomos y particulares.

    Plazos indicados para artículos en stock y días laborables.

    ¿Necesitas cambiar una referencia?

    Si la referencia no es la adecuada, podemos sustituirla en el mismo envío (entrega + recogida en una sola visita), con un ajuste logístico adicional frente a gestionar entrega y devolución por separado.

    Atención al cliente: contacto@vichomeshop.com · 666 33 25 70

    Description

    Digital current indicator with 4-digit LED display, 20 mm high /
    IP 65 front / for 100 V, 250 V, 400 V, 5 A DC
    The digital panel indicator is ideal for measuring and displaying direct current, i.e. direct voltage. The possibility to freely configure the input signal allows for a wide variety of uses for this panel indicator. Thanks to its 4-digit display, the result can be easily read. In addition, with the help of the PCE-PD14 programming adapter, it can be installed on the computer or read from an installation screen. The robust plastic housing of the digital panel indicator protects the device in harsh industrial environments.
    - Screw connection
    - Software configuration
    - 4-digit LED display
    - IP 65 front
    - 100 V, 250 V, 400 V, 5 A DC (selectable)
    - Red on black display
    Input (selectable) ± 100 V DC
    ± 250 V DC
    ± 400 V DC
    0 ... 100 V DC
    0 ... 250 V DC
    ±1 A DC
    ± 5 A DC
    Accuracy ± (0.2 % FS + 1 dgt.)
    Internal resistance 10 Ω ± 1 %
    Scale 2 points
    Display 4 digits, LED display, height: 20 mm
    Display range -1999 ... 9999
    Ambient temperature Operating: -10 °C ... +55 °C
    Storage: -25 °C ... +85 °C
    Dimensions 96 mm x 48 mm x 64 mm
    Panel cutout dimensions 92 mm x 45 mm x (according to DIN)
    Power supply (selectable) 230 V AC
    110 V AC
    24 V AC
    85 ... 253 V AC/DC
    20 ... 40 V AC/DC
    Sensor supply (selectable) 24 V / 30 mA
    Protection type IP 65 front
    Weight < 200 g
    Mounting Mounting clips with clamping screws, connection via terminal strips
    Housing Robust plastic housing
    1 x PCE-N24H Panel indicator
    1 x User manual
